Draw-leaf table with bulbous legs CAD block
A 17th-century English draw-leaf dining table with cup-and-cover turned legs, a low stretcher and an inlaid top, drawn with its leaves closed. At this size it seats six.
Photo: an engraving by an unknown artist, Public domain. Source
- Item
- Draw-leaf table with bulbous legs
- Size
- W 1830 × D 840 × H 785 mm
- Sized by
- Estimated from the photo
- Format
- DXF, millimetres
- Blocks
- TABLE_DRAWLEAF_JACOBEANwith _PLAN, _FRONT and _SIDE
Download the DXF
Free, no sign-in.
What's in the file
- Three blocks
- TABLE_DRAWLEAF_JACOBEAN_PLAN, TABLE_DRAWLEAF_JACOBEAN_FRONT and TABLE_DRAWLEAF_JACOBEAN_SIDE. The plan's insertion point is the back-left corner; the elevations sit at floor level.
- Layers
- Linework is on layer 0 with ByBlock colour, so each block takes the layer you insert it on. Hidden edges are dashed.
- Size
- W 1830 × D 840 × H 785 mm. Estimated from the photo, so check it against the piece you're specifying, and scale it if yours differs.
- Use
- Free for your own projects, including drawings for clients. Please don't share it as part of a block library.
