Sleigh bed (Empire style) CAD block
A New York sleigh bed from about 1805, in the French Empire style: high scrolled ends, a deep side rail, carved eagle heads and paw feet on castors. Drawn as the frame without a mattress, 1473 mm wide and 2350 mm long.
Photo: The Metropolitan Museum of Art, CC0 (public domain). Source
- Item
- Sleigh bed (Empire style)
- Size
- W 1473 × D 2350 × H 1080 mm
- Sized by
- Measured by the museum
- Format
- DXF, millimetres
- Blocks
- BED_SLEIGH_EMPIRE_EAGLEwith _PLAN, _FRONT and _SIDE
What's in the file
- Three blocks
- BED_SLEIGH_EMPIRE_EAGLE_PLAN, BED_SLEIGH_EMPIRE_EAGLE_FRONT and BED_SLEIGH_EMPIRE_EAGLE_SIDE. The plan's insertion point is the back-left corner; the elevations sit at floor level.
- Layers
- The outline is on layer 0 with ByBlock colour, so each block takes the layer you insert it on. Detail lines are on I-FURN-DETL and dashed hidden edges on I-FURN-HIDN, so you can switch either off.
- Size
- W 1473 × D 2350 × H 1080 mm. Measured by the museum, so check it against the piece you're specifying, and scale it if yours differs.
- SketchUp
- The DXF for SketchUp is the same block with a surface in every closed area, so the Paint Bucket fills each one in one click. Import it with Merge coplanar faces ticked: how to import it.
- Use
- Free for your own projects, including drawings for clients. Please don't share it as part of a block library.
