Wingback chair CAD block

An English wing chair from about 1725, upholstered in needlework, with tall wings, rolled arms, a loose seat cushion and cabriole front legs. Drawn at the museum's measurements: 1080 mm wide, 775 mm deep and 1238 mm tall.

An English wing chair in floral needlework upholstery with rolled arms and cabriole legs

What's in the file

Three blocks: WING_CHAIR_QUEEN_ANNE_PLAN, WING_CHAIR_QUEEN_ANNE_FRONT and WING_CHAIR_QUEEN_ANNE_SIDE. The plan's insertion point is the back-left corner; the elevations sit at floor level.
Layers: The outline is on layer 0 with ByBlock colour, so each block takes the layer you insert it on. Detail lines are on I-FURN-DETL and dashed hidden edges on I-FURN-HIDN, so you can switch either off.
Size: W 1080 × D 775 × H 1238 mm. Measured by the museum, so check it against the piece you're specifying, and scale it if yours differs.
SketchUp: The DXF for SketchUp is the same block with a surface in every closed area, so the Paint Bucket fills each one in one click. Import it with Merge coplanar faces ticked: how to import it.
Use: Free for your own projects, including drawings for clients. Please don't share it as part of a block library.
