Panelled chest of drawers on ball feet CAD block
A 17th-century-style oak chest with four long drawers, geometric moulded panels on every drawer front and turned ball feet. The front elevation shows each panel and handle, so it works in a bedroom elevation as well as on plan.
Photo: The Metropolitan Museum of Art, CC0 (public domain). Source
- Item
- Panelled chest of drawers on ball feet
- Size
- W 1070 × D 560 × H 1000 mm
- Sized by
- Estimated from the photo
- Format
- DXF, millimetres
- Blocks
- CHEST_4DRW_BALLFOOTwith _PLAN, _FRONT and _SIDE
Download the DXF
Free, no sign-in.
What's in the file
- Three blocks
- CHEST_4DRW_BALLFOOT_PLAN, CHEST_4DRW_BALLFOOT_FRONT and CHEST_4DRW_BALLFOOT_SIDE. The plan's insertion point is the back-left corner; the elevations sit at floor level.
- Layers
- Linework is on layer 0 with ByBlock colour, so each block takes the layer you insert it on. Hidden edges are dashed.
- Size
- W 1070 × D 560 × H 1000 mm. Estimated from the photo, so check it against the piece you're specifying, and scale it if yours differs.
- Use
- Free for your own projects, including drawings for clients. Please don't share it as part of a block library.
